Standard features and specifications Edit


SOFTWARE Edit

 • Genuine Windows® XP Professional SP2 or Genuine Windows Vista® Business

• Setup, Diagnostics, Online Reference Manual, Adobe® Reader

CPU Edit

• Intel® CoreTM Duo Processor ULV U2400

– 2MB L2 cache

– Processor speed 1.06GHz

– 533MHz FSB

STORAGE & MEMORY Edit

• 512MB SDRAM (DDR2-533) standard, expandable to 1536MB*

(PC2-4200 memory is required)

• 60GB hard drive (shock-mounted and removable**)

• Combo drive (DVD-ROM/CD-RW) standard

DISPLAY Edit

 • 12.1" 1024 x 768 XGA anti-glare TFT active matrix color LCD

• External video support up to 2048 x 1536 and 16.7 million colors

• Intel® 945GMS integrated video controller max. up to 224MB (DVMT) VRAM

AUDIO Edit

 • SigmaTelTM STAC9751 AC-97 v.2.1 compliant

• Intel® high-definition (HD) audio

• Integrated speaker

• Convenient keyboard volume controls (Fn+F5/F6 keys)

EXPANSION SLOTS Edit

• PC card type II x 1

• Secure Digital (SD) card

KEYBOARD & INPUT Edit

• 83-key with dedicated Windows® key

• Electrostatic touchpad with continuous vertical scrolling support

INTERFACE Edit

 • Mini dock box replicator 50-pin

• External video D-sub 15-pin

• Headphones/speaker Mini-jack Stereo

• Microphone/line in Mini-jack

• USB 2.0 (x 2) 4-pin

• 10/100 Ethernet RJ-45

• 56K Modem RJ-11

WIRELESS LAN Edit

 • Intel® PRO/Wireless 3945ABG LAN connection 802.11a/b/g

• Security

– Authentication: LEAP, WPA, 802.1x, EAP-TLS, EAP-FAST, PEAP

– Encryption: CKIP, TKIP, 128-bit and 64-bit WEP, Hardware AES

• Slide on/off switch

POWER SUPPLY Edit

 • Lithium ion battery pack (10.65V, 5700mAh)

• Battery operation: 6.5 hours***

• Battery charging time: approximately 5 hours off, 6.5 hours on***

• AC Adapter: AC 100V-240V 50/60Hz, auto sensing/switching

worldwide power supply

• Pop-up, on-screen battery status reporting

POWER MANAGEMENT Edit

• Resume Function, Hibernation, Standby, ACPI BIOS

SECURITY FEATURES Edit

• Password Security: Supervisor, User

• Security lock slot

• Trusted platform module (TPM) security chip v.1.2

• Computrace® theft protection agent****

WARRANTY Edit

• 3-year limited warranty, parts and labor

DIMENSIONS & WEIGHT Edit

• 10.6"(W) x 1.3"/2.0" (H) x 8.6"(D)

• 2.9 lbs.

INTERGRATED OPTIONS Edit

• Mobile Broadband Solutions

– EVDO

– HSPDA

ACCESSORIES Edit

• AC Adapter (3-pin) CF-AA1623AM

• ToughMate ComUniversal

Carrying Case (large capacity) COMUNIV-P

• ToughMate ComUniversal

Jr. Carrying Case COMUNIVJR-P

• ToughMate Business-rugged

TL Case FMBRTL-P

• External USB Floppy Drive CF-VFDU03U

• Lithium Ion Battery Pack CF-VZSU47U

• Memory Cards

– 512MB CF-WMBAW0512U

– 1GB CF-BAW1024U

• Mini Dock Box Replicator CF-VEBU05BU

• Large Venue DLP Projector PT-DW5100U

• Mobile LCD Projector PT-LB60U

Other Infomation Edit

■ Full Magnesium Alloy Case

■ Shock-mounted Hard Drive

■ Ultra-portable 2.9 lbs.

■ Long-lasting 6.5-hour Battery Life

■ Mobile Broadband-ready Design

Source Edit

http://linuxmeister.net/PDF-info/TOUGHBOOK/toughbook_W5-07.pdf
